Chapter 2 25

IDE channel 0/1 Master,

Slave

Allows you to configure the hard disk drive

connected to the master port of IDE channel. To

enter the IDE Master or Slave setup, press

[Enter]. The IDE CD-ROM is always

automatically detected.

IDE HDD Auto-Detection Press [Enter] to

select this option for automatic device

detection.

IDE Primary/Secondary Master, Slave IDE

Device Setup. You can use one of three

methods:

Auto : Allows BIOS to automatically detect

IDE devices during POST (default)

None : Select this if no IDE devices are

used and the system will skip the automatic

detection step and allow for faster system

start up

Manual : User can manually input the

correct settings

Access Mode : Use this to set the access

mode for the hard drive. the four options are:

CHS/LBA/Large/Auto (default: Auto)

* Cylinder : Number of cylinders

* Head : Number of heads

* Precomp : Write precomp

* Landing Zone : Landing Zone

Sector : Number of sectors

Access Mode allows you to select the access

mode. The options are CHS, LBA, Large,

and Auto.

Drive A The category identifies the types of floppy disk

drive A that has been installed in the computer.

None : No floppy drive installed

360K, 5.25” : 5.25 inch PC type standard

drive ; 360Kbyte capacity

1.2M, 5.25” : 5.25 inch AT-type high-density

drive; 1.2M byte capacity (3.5 inch when 3

Mode is Enabled)

720K, 3.5” : 3.5 inch double-sided drive;

720Kbyte capacity

1.44M, 3.5” : 3.5 inch double-sided drive;

1.44Mbyte capacity

2.88M, 3.5” : 3.5 inch double-sided drive;

2.88Mbyte capacity

Halt On This parameter enables you to control the

system stops in case of Power On Self Test

errors (POST)

No Errors : The system boot will not stop for

any error that may be detected and you will

be prompted

All Errors : Whenever the BIOS detects a

non-fatal error the system will be stopped

All, But Keyboard : The system boot will not

stop for a keyboard error; it will stop for all

other errors (Default value)

All, But Diskette : The system boot will not

stop for a disk error; it will stop for all other

errors

All, But Disk/Key : The system boot will not

stop for a keyboard or disk error; it will stop

for all other errors.

Parameter Description Options
